昇降座
►Vision Ped Plus小型工作室和應用的理想選擇
►Pro-Ped輕型底座可用於攝影棚和轉播車應用。
►Osprey Light專為小型工作室而設計。
►Osprey Elite功能多樣，便攜和全功能相機，
適用於攝影棚和轉播車製作。
►Quartz Two/Quattro-SL and OBL / Quattro SE,非常適合當今的攝影棚及虛擬攝影棚。
►FP-188 +機器控制或手動雲台基座 。
►新型FPR-210 +提供高承載重量的機器控制雲台基座 。
►Vinten FE-55升降裝置提供較高的拍攝高度，可在小型工作室中實現最大的靈活性。
商品介紹
Vision Ped Plus
| Model No.: | V3951-0001 |
| Max. Capacity: | 30 kg / 66 lbs |
| Height Range: | 75 to 160 cm / 29.5 to 63 " |
| Weight: | 13.7 kg / 30.2 lbs |
| On-Shot Stroke: | 41 cm / 16.1 " |
| Tracking Width: | 69 cm / 27 " |
| Wheel Diameter: | 10 cm / 4 " |
| Steering Ring Diameter: | 38 cm / 15 " |
| Wheel Lock: | Yes |
| Colour: | Grey |
Pro Ped Pedestal
| Model No.: | 3983-3C Studio [for OB version please see below] |
| Max. Capacity: | 55 kg / 121 lbs [max. capacity includes trim weights] |
| Height Range: | 66.6 to 148.5 cm / 26.2 to 58.4 " |
| Weight: | 28.5 kg / 62.8 lbs |
| On-Shot Stroke: | 41 cm / 16.1 " |
| Tracking Width: | 95 cm / 37.4 " |
| Transit Width: | 86 cm / 33.8 " |
| Wheel Diameter: | 12.5 cm / 5 " |
| Steering Ring Diameter: | 53.4 cm / 20.8 " |
| Wheel Lock: | Yes |
| Trim Weights: | 3.5 kg / 7.5 lbs |
| Ground Clearance: | 1.9 cm / 0.75 " |
| Colour: | Black |
| Model No.: | 3983-3B OB |
| Max. Capacity: | 55 kg / 121 lbs [max. capacity includes trim weights] |
| Height Range: | 67.8 to 149.7 cm / 26.7 to 58.9 " |
| Weight: | 28 kg / 61.7 lbs |
| On-Shot Stroke: | 41 cm / 16.1 " |
| Tracking Width: | 95 cm / 37.4 " |
| Wheel Diameter: | 15 cm / 6 " |
| Steering Ring Diameter: | 53.4 cm / 20.8 " |
| Wheel Lock: | Yes |
| Trim Weights: | 3.5 kg / 7.5 lbs |
| Ground Clearance: | 3.15 cm / 1.2 " |
| Colour: | Black |
Ospery Eilte Pedestal
| Model No.: | 3574-3C Studio [for OB version please see below] |
| Max. Capacity: | 75 kg / 165 lbs [max. capacity includes trim weights] |
| Height Range: | 66 to 143 cm / 26 to 56 " |
| Weight: | 45.7 kg / 101 lbs |
| On-Shot Stroke: | 77 cm / 30.3 " |
| Wheel Lock: | Yes |
| Tracking Width: | 97 cm / 38.2 " |
| Transit Width: | 80 cm / 31.5 " |
| Narrow Transit Width: | 72.3 cm / 28.5 " |
| Wheel Diameter: | 12.5 cm / 5 " |
| Detachable Steering Ring Diameter: | 53.3 cm / 21 " |
| Trim Weights: | 3.5 kg / 7.7 lbs |
| Ground Clearance: | 2 cm / 0.8 " |
| Model No.: | 3574-3B OB |
| Max. Capacity: | 75 kg / 165 lbs [max. capacity includes trim weights] |
| Height Range: | 68.5 to 145.5 cm / 27 to 57.3 " |
| Weight: | 48.7 kg / 107.4 lbs |
| On-Shot Stroke: | 77 cm / 30.3 " |
| Wheel Lock: | Yes |
| Tracking Width: | 97 cm / 38.2 " |
| Transit Width: | 80 cm / 31.5 " |
| Narrow Trasit Width: | 72.3 cm / 28.5 " |
| Wheel Diameter: | 16 cm / 6.3 " |
| Detachable Steering Ring Diameter: | 53.3 cm / 21 " |
| Trim Weights: | 3.5 kg / 7.7 lbs |
| Ground Clearance: | 3.45 cm / 1.2 " |
| Colour: | Black |
Quartz Two Pedestal
| Model No.: | 3826-3 |
| Max. Capacity: | 80 kg / 176.4 lbs [max. capacity includes trim weights] |
| Height Range: | 66 to 143 cm / 26 to 56 " |
| Weight: | 88.9 kg / 187.4 lbs |
| On-Shot Stroke: | 77 cm / 30.3 " |
| Tracking Width: | 108 cm / 42 " |
| Transit Width: | 80 cm / 31.5 " |
| Wheel Diameter: | 12.5 cm / 5 " |
| Detachable Steering Ring Diameter: | 63.5 cm / 25 " |
| Trim Weights: | 3.5 kg / 7.7 lbs |
| Ground Clearance: | 2 cm / 0.8 " |
| Colour: | Black |
Quattro-L Pedestal
| Model No.: | V3852-0003 |
| Max. Capacity: | 105 kg / 231.5 lbs [max. capacity includes trim weights] |
| Height Range: | 46.2 to 149 cm / 18.2 to 58.7 " |
| Weight: | 158 kg / 348.4 lbs |
| On-Shot Stroke: | 100 cm / 39.4 " |
| Tracking Width: | 107 cm / 42.1 " |
| Transit Width: | 92.4 cm / 36.4 " |
| Wheel Diameter: | 16 cm / 6.3 " |
| Detachable Steering Ring Diameter: | 74 cm / 29 " |
| Trim Weights: | 7.5 kg / 16.5 lbs |
| Ground Clearance: | 2.8 cm / 1.1 " |
| Colour: | Black |
Quattro-OBL Pedestal
| Model No.: | V4002-0002 |
| Max. Capacity: | 105 kg / 231.5 lbs [max. capacity includes trim weights] |
| Height Range: | 50.8 to 150.8 cm / 20 to 59.4 " |
| Weight: | 116 kg / 255.8 lbs |
| On-Shot Stroke: | 100 cm / 39.4 " |
| Tracking Width: | 98 cm / 38.5 " |
| Transit Width: | 87 cm / 38.5 " |
| Wheel Diameter: | 20 cm / 7.8 " |
| Detachable Steering Ring Diameter: | 59 cm / 23.2 " |
| Trim Weights: | 7.5 kg / 16.5 lbs |
| Ground Clearance: | 5 cm / 2 " |
| Colour: | Black |
Quattro-SL Pedestal
| Model No.: | V3963-0002 |
| Max. Capacity: | 80 kg / 176.4 lbs [max. capacity includes trim weights] |
| Height Range: | 47 to 147 cm / 18.5 to 57.8 " |
| Weight: | 136 kg / 300.6 lbs |
| On-Shot Stroke: | 100 cm / 39.4 " |
| Tracking Width: | 81 cm / 31.9 " |
| Transit Width: | 74.5 cm / 29.3 " [with small steering ring] |
| 82 cm / 32.2 " [with large steering ring, fitted as standard] | |
| Footprint: | 80.6 x 74.5 cm / 31.8 x 29.4 " |
| Wheel Diameter: | 12 cm / 4.9 " |
| Detachable Steering Ring Diameter: | 74 cm / 29 " |
| Trim Weights: | 7.5 kg / 16.5 lbs |
| Ground Clearance: | 2 cm / 0.8 " |
| Colour: | Black |
Vinten Quattro-SE
| Part Number | V3851-0001 * V3851-0002 ** |
| Maximum Height | 1498 mm / 58.9 ” |
| Minimum Height | 498 mm / 19.6 ” |
| Weight (Without Trim Weights) | 136.35 kg / 300.6 lbs |
| Maximum Payload | 85 kg / 187 lbs |
| On Shot Stroke | 1000 mm / 39.4 “ |
| Transit Doorway Width (With Small Steering Ring) |
74.5 cm / 29.3 “ |
| Transit Doorway Width (With Large Steering Ring) |
82 cm / 32.3 “ |
| Ground Clearance | 20 mm / 0.78 “ |
| Cable Guards | Single Point Action |
| Repeatability | X & Y +/- 70mm +/- 1° (triangle move) |
| Degrees of Freedom - Pedestal only | 4 X, Y, Z & Base Orientation |
| Degrees of Freedom - additional to pedestal, but included in serial protocol output |
4 (P, T, Z, and F) |
| Resolution (X, Y, Z) | ±<1mm |
| Resolution (Orientation) | ± 0.02° |
| Position Protocol for VR system | Available on request |
| FP-188 | V3952-0006 |
| VR upgrade | VR PED UPGRADE |
| Height Range | 660 mm - 1430 mm / 26 ” - 56 ” |
| On Shot Stroke | 770 mm / 30 ” |
| Doorway Tracking Width | 800 mm / 32 ” |
| Steering Ring Diameter | 635 mm / 25 ” * |
| Maximum Floor Speed | 300 mm / 12 ” / second |
| Minimum Floor Speed | 25 mm / 1 ” / second |
| Maximum Height Speed (On Shot) | 150 mm / 6 ” / second |
| Manual Operation | Yes |
| Power Consumption Peak | 750W |
| Power Input | Auto ranging 110-240V AC 50/60 Hz |
| Max Payload | 85 kg / 188 lbs |
| Repeatability X & Y = Z = X & Y = |
+/- 100mm +/- 5mm +/- 1.5° (after triangle test pattern) |
| Degrees of freedom | 3, X,Y,Z Degrees of freedom additional to pedestal but included in D1 serial packet: P, T, Z & F |
| Resolution | (X,Y,Z) = +/- <1mm |
FPR-210+
Part Number V3952-0005 or V3952-0008 fitted with APS
Payload 95 kg / 210 lbs
Pedestal weight 130 kg (286.6 lbs)
Height range 660 mm (26 in.) - 1430 mm (56.3 in.)
Doorway tracking width 779 mm (30.7 in.)
Floor speed range 25 mm / sec (1.0 in. / sec) to 300 mm / sec (12 in. / sec)
Column speed range 10 mm / sec (0.4 in. / sec) to 150 mm / sec (5.9 in. / sec)
Power 110-240V AC 50/60 Hz 750W
| FE-55 | |
| Part number | V4127-0001 |
| Height range | 741-1431 mm (29.2-56.3 in) |
| Max. speed | 100 mm/s (3.9 in/s) |
| Max. payload | 25 kg (55 lb) |
| Width | 690 mm (27.2 in) |
| Ground clearance | 25 mm (1 in) |
| Power inlet | 100-240 V AC Autoranging 50/60Hz |
| Power outlets | Dual 100-240 VAC AC Autoranging 50/60Hz |
